JBH Indoor Foldable Elderly Electric Wheelchair

Unfolded Size                                                              1000X640X880 mm
———————————————————————————————————————
Folded Size                                                                     640X380X880 mm
———————————————————————————————————————
Driving Speed                                                                                0~6 km/h
———————————————————————————————————————
Max drive distance                                                                             30 km
———————————————————————————————————————
Max Capacity                                                                                    140 kgs
———————————————————————————————————————
Weight                                                               27.5 kgs (Without Battery)
———————————————————————————————————————
Safe Gradient                                                                                       0~12°
———————————————————————————————————————
Motor                                                                                             24V 250W
———————————————————————————————————————
Lithium Battery                                                                                24V 6AH
———————————————————————————————————————
Brake System                                                          Electromagnetic Brake
———————————————————————————————————————


Availability:
linkedin sharing button
facebook sharing button
wechat sharing button
whatsapp sharing button
sharethis sharing button
  • D17

  • JBH

D17详情页_01


Product Description

JBH electric wheelchair D17 is similar to D08, but the function is upgraded. D17 can remotely adjust the tilt Angle of the backrest, D17 rear wheel is larger and more stable, D17 is suitable for the elderly indoor and outdoor use


Product Characteristics

1. The Angle of backrest can be adjusted by remote control

2. The rear wheel adopts 12 inches, which is more stable during driving

3. Adjustable seat width and handrail height, suitable for different groups of people

4. Foot height can be adjusted

5. Standard with three batteries, more durable

D17详情页_02

D17详情页_04

Data Sheet

Overall Size 1000*640*880  mm
Fold Size 640*380*880  mm
Height Armrest 150-240 mm(adjustable)
Seat Width 500-620  mm(adjustable)
Net Weight

27.5KG

Gross Weight

37KG


Batteries

24v  6AH *3
Ternary lithium Battery
Motor  24V 250W Brushless
Controller 24V/30A  Brushless
Front Wheel Size 8”
Rear Wheel Size 12”
Max. Inclination 12°
Speed  0-6km
Turning Radius 80cm

配件

Accessories

1. Head cushion

2. Cargiver control intallation kits

3. Cell phone holder

4. Storage bag

5. Leg brace

6. Atachable rear seat

7. Travel bag

8. Flashlight

9. Cup holder
